Our FRP gratings are engineered to perform in the most aggressive and corrosive environments. Designed for long-term durability, they deliver excellent resistance to chemicals, moisture, and harsh industrial conditions. To match specific application needs, we offer gratings in a range of high-performance resin systems, including Orthophthalic, Isophthalic, Vinyl Ester, and Phenolic—ensuring the perfect balance of strength, safety, and corrosion protection.
Available range of Sizes:
| Panel Height (mm) |
Mesh Size (mm) |
Panel Size (W × L) (mm) |
Rib Thickness (mm) |
Open Area (%) |
| 25 |
38 × 38 |
1220 × 3660 |
7/5 |
68 |
| 25 |
38 × 38 |
1000 × 3000 |
7/5 |
68 |
| 25 |
38 × 38 |
1529 × 4039 |
7/5 |
68 |
| 25 |
19 × 19 |
1220 × 3660 |
7/5 |
40 |
| 30 |
38 × 38 |
1220 × 3660 |
7/5 |
68 |
| 30 |
38 × 38 |
1529 × 4039 |
7/5 |
68 |
| 38 |
38 × 38 |
1220 × 3660 |
7/5 |
68 |
| 38 |
38 × 38 |
1000 × 3000 |
7/5 |
68 |
| 38 |
38 × 38 |
1529 × 4039 |
7/5 |
68 |
| 38 |
19 × 19 |
1220 × 3660 |
7/5 |
40 |
| 50 |
50 × 50 |
1220 × 3660 |
7/5 |
78 |
| 50 |
38 × 38 |
1220 × 4000 |
11/9 |
51 |
| 50 |
25 × 25 |
1220 × 3660 |
7/5 |
55 |
Resin Grades
| Resin Type |
Resin |
Description |
Flame Spread Index |
| Type IFR |
Isophthalic Polyester |
Industrial Grade corrosion resistance & fire retardant |
Class 1, 25 or less |
| Type I |
Isophthalic Polyester |
Industrial Grade corrosion resistance in acidic environment |
Non fire retardant |
| Type V |
Vinyl Ester |
Superior corrosion resistance & fire retardant |
Class 1, 25 or less |
| Type P |
Phenolic |
Low smoke emission & superior fire retardant |
Class 1, 5 or less |
Finish
Plain Concave Meniscus
Quartz Gritted Anti Skid
Chequered Plate Top Surface
